Manufacturer : Matek / Référence : *CANPDB-4A

CANPDB w/ 4A BEC & JST-GH Splitter By Matek

En stock
€16.90
Last items in stock

2 points loyalty thanks to this product

Thanks to our loyalty program, you collect 1 point with each 10 euros you spend. The points will be collected in your personal account. 1 loyalty point will count for your voucher as 0.2 euros.

Shipping costs from 49€ pour France
Same day shipping for orders placed before 3:30pm (Monday to Friday)

Related accessories

Related products

Technical characteristics

This CANPDB from Matek will allow you to plug four CAN devices into one plug.

*Power and distance are subject to specific regulations, be sure to respect those established in the country where you are playing.


Specifications

  • 6V to 55V Operating Input Range(2S-12S Li-xx)
  • 5.2V output on “5V” pin/pads
  • Support total 4A Continuous load current. 1A for each JST-GH port
  • Maximum Duty Cycle: 100%,   when input voltage< setting value,  Regulator output voltage = Input voltage
  • No protection for reversed input polarity
  • Output Short-circuit tolerant (3 seconds)
  • 5x CAN-H/CAN-L are in parallel
  • CAN port connector: JST-GH 4pin(SM04B-GHS-TB)
  • Size & Weight: 38 x 26 x 7.8mm
  • Weight : 12g

Included

  • 1x CANPDB-4A
  • 1x  JST-GH-4P to JST-GH-4P 20cm silicon wire
