Manufacturer : AXIS Flying / Référence : ARGUS-F7-AIO
Argus F7 AIO By AxisFlying
Hors stock
€96.90
Shipping costs
from 49€ pour France
Same day shipping
for orders placed before 3:30pm (Monday to Friday)
Related accessories
Technical characteristics
New AIO from AxisFlying from the Argus series.
This F722 40A is available as a board alone or with a heatsink.
Compatible with DJI O3, the AIO Argus has a barometer, an OSD and an ICM42688P gyro.
The Argus F7 AIO mounts in 25.5x25.5 and 26.5x26.5mm (M3) and supports BLHeli_S and 4-6S LiPo batteries.
FC
- Target: AXIS ARGUS F7 AIO
- O3 plug
- Baro: supported
- BEC: 5V/3A
- Beeper: supported
- Size: 36*36*7.2mm
- MCU: STM32F722RET6
- Gyro: ICM42688P
- UARTs: 5
- OSD: Supported
- LEDs: Supported
- Mounting: 25.5/25.5mm
- Weight (with heatsink): ~14.7g
- Weight (without heatsink): ~8.8g
ESC
- Voltage: 4-6S
- Current: 40A
- Burst: 50A (10s)
- Target: BLHeli_S
- Amperage meter : 210 scale
- Bluejay (default)
Included
- 1x Argus F722 40A AIO
- 2x Silicone cable
- 1x 35V 270uF Capacitor
- 1x XT60H male connector
- 8x Damper
- 1x 6pin cable
Note : DJI O3 not included
Customer reviews
Très bien 👍
Pas encore montée mais je pense que c’est une valeur sûre.
Pas encore montée et je pense que c’est une valeur sûr… 🤓👍
Les ESC n'ont pas encore brûlés donc je valide 😂 Attention au format de montage..
On branche les moteurs, 2-3 config sur betaflight et c'est parti ! Par contre l'emplacement des soudures n'est pas facile.
