Manufacturer : BETAFPV / Référence : 01040016_2

Air Brushless G473 5A 5in1 AIO V1.0 By BetaFPV

Hors stock
€50.90
Out-of-Stock Notify me when the product is available again

6 points loyalty thanks to this product

Thanks to our loyalty program, you collect 1 point with each 10 euros you spend. The points will be collected in your personal account. 1 loyalty point will count for your voucher as 0.2 euros.

Shipping costs from 49€ pour France
Same day shipping for orders placed before 3:30pm (Monday to Friday)

Related accessories

Related products

Technical characteristics

BetaFPV's G473 brushless AIO is the first 1S using the STM32G473CEU6.

Equipped with the ICM42688P gyroscope, 5A ESC, 5.8G 25-400mW VTX and an ExpressLRS 2.4G receiver, this AIO is very lightweight and will allow you to manage your drone's posture and movement precisely to a higher level.

This is the advanced choice for future ultra-light 1S drones such as the Whoops Air65 and Air75.

Note : upon receipt of your item, please connect it via USB and calibrate the accelerometer before starting to solder.

FC

  • Weight: 3.6g
  • Mounting Hole Size: 26mm x 26mm
  • CPU*: STM32G473CEU6 (168MHz)
  • Six-Axis: ICM42688P (SPI connection)
  • Blackbox Memory: 16MB
  • Sensor:  Voltage&Current
  • 5V BEC*: 5V 3A
  • USB Port: SH1.0 4-Pin
  • Built-in ESC with 5A continuous
  • 5IN1 Version: FC+ESC+OSD+VTX+RX

ESC

  • Input Voltage: 1S
  • FC Firmware Version: Betaflight_4.5.0_BETAFPVG473
  • ESC Firmware: A_X_5_96KHz_V0.19.hex for BB51 Bluejay hardware
  • Signal Support: D-shot300, D-shot600

VTX

  • Output Power: 25/100/200/400/PIT
  • Frequency: 5.8GHz 48 channels, with Raceband: 5658~5917MHz
  • Channel SEL: SmartAudio2.0
  • Modulation Type: FM
  • Frequency Control: PLL
  • All Harmonic: Max -50dBm
  • Frequency Stability: ±100KHz (Typ.)
  • Frequency Precision: ±200KHz (Typ.)
  • Channel Carrier Error: ±1.5dB
  • Antenna Port: 50 Ω
  • Operating Temperature: -10℃~+80℃

Included

  • 1x Air Brushless Flight Controller
  • 1x Type-C to SH1.0 Adapter
  • 1x SH1.0 4Pin Adapter Cable
  • 1x 5.8g VTX Antenna
  • 1x BT2.0 U Whoop Cable Pigtail | 40mm
  • 4x M1.4*4 Self-tapping Screws
  • 4x Shock Absorbing Ball
