Gazer Analog Camera By CaddxFPV
Related accessories
Technical characteristics
Take your flights to the next level with unmatched visibility, day or night with the Gazer camera from CaddxFPV.
Thanks to its ultra-low-light color night vision technology, the Gazer camera delivers bright, sharp, and vivid color images, even in complete darkness. Its AI-powered image enhancement algorithm dynamically boosts brightness, reduces noise, and restores realistic colors, ensuring clear vision in all conditions.
Equipped with a 3x optical zoom and free from distortion, it provides perfect clarity—from close-up shots to long-range views. The removable day/night filter can be switched via the flight controller, offering instant adaptation to changing light conditions.
Versatile and high-performance, the Gazer camera is ideal for any mission, delivering exceptional image quality and crisp detail whenever you need it.
Specifications
- Image sensor : 1/1.8 inch
- Resolution sensor : 1920x1080(2MP)
- Resolution ouput : 720x576
- Horizontal resolution : 1500TVL
- Focal length : 2.8mm
- Aperture : F1.0
- FOV : 131.6°
- Filter : Manually removable
- Output format : PAL
- Frame rate : 50fps
- Magnification : 3x (zoomed in by FC)
- Image quality : D/N (switched by FC) It is recommended to install the filter and use D mode during the day, and remove the filter and use N mode at night
- Aspect ratio : 4:3
- Video interface : 1xPAL
- Supply Voltage : 9~24V
- Typical Power Consumption : <2W
- Operating temperature : -20℃~60℃
- Dimensions camera : 20x20x28.54mm
- Dimensions AI Box : 34x34x8.65mm
Included
- 1x Gazer
- 1x Quick start guide
- 1x 6pin silicone cable
- 1x 3pin silicone cable
- 1x Set of screws
