Manufacturer : Iflight / Référence : X017622
Iflight - Unibell XING2 2207 Black - 2050Kv Motor
En stock
€22.90
Shipping costs
from 49€ pour France
Same day shipping
for orders placed before 3:30pm (Monday to Friday)
Related accessories
Technical characteristics
The iFlight XING series motor is designed and named by FPV pilot & specialist Patrick Xing.
The iFlight XING series motors were designed and named by pilot and FPV specialist Patrick Xing.
New Xing2 Black range!
Features
- 5mm titanium alloy shaft, our strongest prop shaft ever!
- Crash resistant 7075 aluminum bell
- Smooth and long-lasting NSK 9x4x4 bearings
- Center slotted N52H curved arc magnets
- XING O-ring bearing gap protection
- Motor wires protector
- Dynamically balanced
Specifications
- KV: 2050KV
- Weight(included wire): 30.5g
- Dimension: φ29*32.25mm
- Interphase Resistance: 56.3mmΩ
- Input Volts: 25.2V
- Peak Current: 46.05A
- Max Watt: 706.9W
- Mounting Holes: 16*16 φ3mm
- Rotor Specifications: Unibell
- Shaft Diameter: 5mm
- Shaft Protruding Length: 13.5mm
- Lead: 160mm/20AWG
- Magnet: N52H Curved
- Configuration: 12N14P
- Bearing Type: NSK
- Bearing Specification: φ9*φ4*4
- Winding: Single Strand copper winding
Included
- 1x XING2 2207 Black Brushless Motor
- 4x M3*10 screws
- 1x M5 Flanged Nylon Insert Lock Nut
