Manufacturer : NewBeeDrone / Référence : 03AG07

HummingBird V4 AIO ELRS 2.4G w/ 25-400mW VTX By NewBeeDrone

En stock
€53.90
Same day shipping

6 points loyalty thanks to this product

Thanks to our loyalty program, you collect 1 point with each 10 euros you spend. The points will be collected in your personal account. 1 loyalty point will count for your voucher as 0.2 euros.

Shipping costs from 49€ pour France
Same day shipping for orders placed before 3:30pm (Monday to Friday)

Related accessories

Related products

Technical characteristics

This HummingBird V4 AIO is specially designed for the HummingBird V4 BNF drone and is not intended for other assembly projects.

Compatible with the Mark3 camera, this analog AIO from NewBeeDrone is mounted in 25.5*25.5mm and consists of a FC F411, a 12A ESC and a 25mW VTX.

* Important note: French regulations impose a maximum power of 25mW in the 5.8 Ghz frequency, as well as dual control piloting to practice immersion flight (FPV). The responsibility of Drone-FPV-Racer cannot be engaged for any use of this material without an adequate license.

Specifications

  • MCU: STM32F411
  • VTX:  25-100-400mW (max)mw with BeeTX 5.8Ghz Antenna
  • Gyro : BMI270
  • ESC: 12A BLHeliS Pre-Flash with Bluejay 0.20 target: O-H-5 48khz
  • ESC Connector: JST-1.0 3Pin
  • OSD: NBD7456 Graphical OSD compatible with Betaflight OSD
  • Receiver: 2.4G Antenna with MHF3 connector
  • Flight Controller Weight: 4.57g(Include antennas and battery connector) RS 3.23
  • Flight Controller Size: Outer dimensions: 29x29x7.6mm
  • Flight Controller Holes: 25.5x25.5mm
  • Battery input: 1S Only
  • Uart1: free
  • Uart2: free
  • Power Plug: Nectar Connector Gold Plated PH2.0 Solid Pin

Included

  • 1x AIO HummingBird
  • 1x Set of screws
