Manufacturer : Flywoo / Référence : FW19003222
GOKU GN745 45A AIO 32Bit MPU6000 V3 By Flywoo
En stock
€102.90
Shipping costs
from 49€ pour France
Same day shipping
for orders placed before 3:30pm (Monday to Friday)
Related accessories
Technical characteristics
The GOKU GN745 AIO adopts fully plug&play connectivity, much simpler and faster for your assemblies. With a 25.5*25.5mm mounting, the GN745 V3 is equipped with an STM32F745 chip, AM32 firmware, an MPU6000 gyro, a dual BEC, a barometer and 7 UARTs ports.
Compatible with digital and analog VTX, the 45A AIO supports 2-6S Lipo voltage and BF, INAV and ArduPilot platforms.
Specifications
- BF Flight Controller Firmware: FLYWOOF745AIO
- INAV Firmware: FLYWOOF745
- Ardupilot Firmware: FLYWOOF745
- MCU: STM32F745 32-bit processor,216MHz, 1MB Flash
- IMU: MPU6000 (SPI)
- Barometer: SPL06
- USB VCP Driver (all UARTs usable simultaneously; USB does not take up a UART)
- 7 hardware UARTS (UART1,2,3,4,5,6,7)
- Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only.
- PPM and PWM receivers are not supported.
- Onbord 16Mbytes for Blackbox logging
- 5V Power Out: 2.0A max
- 3.3V Power Out: 0.5A max
- Dimensions: 33.5x33.5mm
- Mounting Holes: Standard 25.5/26.5mm square to center of holes
- Weight: 9.4g
Onboard 4in1 ESC
- Support AM32
- Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600,Dshot1200
- Input Voltage: 2-6S Lipo
- Continuous Current: 45A
- Firmware: GOKU_F4A32_PRO
Included
- 1x GN745 AIO
- 1x UNICON UPL Capacitor 25V 470UF
- 4x M2x6.6 Shock-Absoring Ball
- 4x M2 Rubber Ring
- 1x XT30 Power Cable
- 1x DJI O3 Connection Cable
- 1x VTX & Camera Connection Cable
- 1x Receiver Connection Cable
- 1x GPS Compass Connection Cable
