Detailed Description

This DarwinFPV F411 15A AIO is mounted in 25.5*25.5mm and has a compact and safer.

Enjoy a built-in ELRS 2.4G receiver, an MPU6500 gyro, an OSD and a 5V/2A BEC.

Upon receiving your FC,please connect to USB and calibrate before continuing to build and solder to it.

Specifications

Processor F4
Amp 15A
Protocol ELRS 2.4G
Voltage 3S
Gyro MPU6500
Mount Size 25.5x25.5mm
ESC Firmware Bluejay

Specifications

  • Input voltage : 1-3S
  • Mounting : 25.5*25.5mm
  • Dimensions : 31*31*7mm
  • Weight : ~5.4g
  • FC main control chip : STM32F411
  • Gyro : MPU6500
  • OSD : AT7456E
  • Blackbox : No
  • Baro : No
  • Bluetooth : No
  • Receiver : Onboard SPI ELRS 3
  • BEC : 5V/2A
  • USB interface : 1x Micro USB
  • Serial port : UART1, UART2
  • Soft serial port : No
  • RSSI : No
  • RGB : Onboard
  • Buzzer : 1x BB
  • Firmware FC : DARWINF4SX1280HD
  • ESC : 15A ELRS
  • ESC main control chip : EFM8BB21
  • Current : 4x15A
  • Peak : 4x17A (5S)
  • Supports Dshot 150/300/600
  • Galvanometer : No
  • Telemetry : No
  • ESC firmware : S_H_50

45A ESC

  • Main control chip : EFM8BB21
  • Input voltage : 3-6S LiPo
  • Current : 4x45A
  • Peak : 4x55A (5s)
  • Support throttle protocol : Dshot 300/600
  • Galvanometer : Support
  • Firmware : J_H_40 (Bluejay)
  • Power cable : #16AWG/120mm
  • Mounting : 25.5*25.5mm
  • Dimensions : 38*38*4mm
  • Weight : ~6.6g

Included

  • 1× DarwinFPV F411 15A ELRS AIO
  • 5× Motor socket (SH1.25 female)
  • 1× Power cord (#20AWG /70mm)
  • 1× XT30
  • 5× M2*6.6 shock absorber ball
  • 1× 2.4G RF113 IPEX1 86mm silver-plated antenna
  • 1× Spare screw package (M2*8)
  • 1× Sticker
