Detailed Description

This F405 mini 20x20 flight controller is equipped with an 8Mb blackbox, an ICM42688P gyroscope, a barometer, an OSD and supports Bluetooth.

Specifications

Video DJI FPV
Video Analog
Video DJI O3
Processor F4
Voltage 6S
Gyro ICM42688-P
Barometer With Baro

Specifications

  • MCU : STM32F405
  • IMU(Gyro) : ICM42688P
  • USB Port Type : Type-C
  • Barometer : Built-in
  • OSD Chip : AT7456E chip
  • BLE Bluetooth : Supported
  • WIFI : Not supported
  • DJI Air Unit Connection Way : Direct soldering
  • Compatible with all DJI Air Units: DJI O3/RunCam Link/Caddx Vista/DJI Air Unit V1
  • Blackbox : 8MB Onboard Flash
  • Power Input : 3-6S
  • UART : 6 sets
  • I2C : Supported
  • Buzzer : BZ+ and BZ- pad used for 5V Buzzer
  • RSSI Input : Not Supported
  • Smart Port / F.Port : Not Supported
  • Supported Flight Controller Firmware : BetaFlight(Default), INAV
  • Firmware Target Name : SPEEDYBEEF405MINI
  • Mounting : 20x20mm
  • Dimension : 30(L) x 32(W) x 7.8(H)mm
  • Weight : 9.6g

Included

  • 1x FC F405 mini
  • 1x Manual
  • 1x 8pin JST Cable
  • 1x DJI 6pin Cable
  • 5x M2*7.6mm grommet
  • 5x M3*6.6mm grommet
