Raptor Antenna 5.8Ghz - Menace RC - LHCP

MenaceRC

The Raptor antenna is a small compact Omni that delivers a smooth radiation pattern and a high axial ratio with its unique PCB pagoda construction designed by Maarten Baert.

Learn more

By buying this product you can collect up to 1 loyalty point. Your cart will total 1 loyalty point that can be converted into a voucher of 0,20 €.

Produit indisponible pour le moment

X

Get emailed when we have stock again


10,40 €

  • Degressive Shipping Costs

  • Same day shipping for orders placed before 3:30 pm (Monday to Friday)

More info

The Raptor antenna is a small compact Omni that delivers a smooth radiation pattern and a high axial ratio with its unique PCB pagoda construction designed by Maarten Baert.

Features

  • Small 5.8Ghz Aero design with excellent omni directional pattern
  • Unique PCB construction allows manufacturing within fine tolerances
  • Gain 1.09db with a radiation efficiency of 92%
  • Clearer video reception with upto 20% greater signal received than other omni antenna topology with higher gain
  • High Axial Ratio for reversed polarity rejection, ideal for send and receive as a pair.
  • Robust injection moulded case for crash protection
  • Weighs less than 10grams



Specification

  • Centre frequency 5.8 GHz
  • Frequency Range: 5550 – 6050 MHz
  • Matching S11 < -20dB, VSWR <1.22
  • Gain: 1.09dB with efficiency: 92%
  • Axial Ratio <1.3
  • Beam width: 360 degrees
  • Left Hand Circular Polarised (LHCP)
  • SMA Connector
  • Height: 85mm
  • Weight: 9.4grams
