QAV-PRO Nano Whoop 2" Cinequads Edition Frame Kit By Lumenier

Out of stock
€83.25

View More Info
This product earns you 9 loyalty points.

Thanks to our loyalty program, you collect 1 point with each 10 euros you spend. The points will be collected in your personal account. 1 loyalty point will count for your voucher as 0.2 euros.

Ajouter à la Wishlist
QAV-PRO Nano Whoop 2" Cinequads Edition Frame Kit By Lumenier - Drone-FPV-Racer.com

Other reliable and tested choices

Ce produit est actuellement en rupture, mais pas de panique. Nous vous proposons une sélection d’articles similaires, testés et approuvés, pour répondre aux mêmes besoins et vous permettre de finaliser votre setup sans compromis.

Detailed Description

The QAV-PRO Nano Whoop from the Cinequads series is an ultra-light and versatile 2" quad with less than 250g on the scale, which makes it a small and agile Cinewhoop.

This is a great tool for cinematics featuring full propeller protection with premium lightweight carbon fiber.

Compatible with the DJI O3 system, the QAV-Pro Nano will allow you to work in tighter spaces, where larger quads cannot go.


Specifications

Video DJI O3
Model QAV-PRO

Bullet points

  • Vibration isolating camera mounting system for video stabilization software compatibility
  • Designed in Germany by Cinequads in collaboration with Lumenier
  • Specially designed O3 heatsink
  • Supports naked action cameras
  • Ultralight weight at 47.6g
  • Ducted for indoor safety
  • Pusher style frame
  • 4S capabilities
  • O3 optimized
  • Sub 250g

Specifications

  • Camera Plates: Carbon Fiber with Dampeners
  • VTX/AIO Mounting Patterns: 25x25mm
  • Antenna Mount Material: Aluminum
  • Motor Mounting Pattern: 9x9mm
  • Carbon Fiber Thickness: 1.5mm
  • Standoffs: M2x16mm Aluminum
  • O3 Heatsink Mounts: Aluminum
  • Dimensions: 6.3x5x1.5 inches
  • Camera Mounts: Aluminum
  • Connector: XT30
  • Weight: 47.6g

Recommended parts (not included)

  • 550mAh 4S 80c LiPo Battery (XT-30)
  • Propellers: Gemfan D51-4 Propellers
  • Propellers: HQProp T51MMX6
  • AIO: BETAFPV AIO V4 - F405 4S FC + 20A BLHeli_32 ESC
  • Motors: Lumenier ZIP V2 1303.5 motor
  • Propellers: HQProp T2X2X3
  • VTX/Camera: DJI O3 Air Unit

Included

  • 1x Lumenier QAV-PRO Nano Whoop Bottom Plate
  • 1x Lumenier QAV-PRO Nano Whoop Top Plate
  • 1x 3D Printed Universal Camera Mount Base
  • 1x USB-C to 90° USB-C Extension Cable
  • 2x Carbon Camera Isolation Plate
  • 1x Lumenier Elastic LiPo Strap
  • 1x O3 Mounting Heatsink Kit
  • 2x Aluminum Camera Mount
  • 1x XT30 3D Printed Mount
  • 4x Rubber Grommets
  • 4x M2 Steel Hex Nut
  • 1x XT30 Connector
  • 1x Antenna Mount
  • 4x Landing Feet
  • 1x Hardware Kit
  • 1x Battery Pad
  • 6x Standoffs
  • 6x Zip Ties

Vidéo

Technical Documents

Manual (1.17MB)
