Manufacturer : T-Motor / Référence : TMOTOR-F7-FC-PRO
F7 PRO Flight Controller By T-Motor
En stock
€82.42
Shipping costs
from 49€ pour France
Same day shipping
for orders placed before 3:30pm (Monday to Friday)
Related accessories
Technical characteristics
T-Motor's first F7 Flight Controller has arrived! Logical layout, designed to work seamlessly with the T-Motor ESC F45 et F55.
New T-Motor flight controller, DJI compatible F7 PRO has barometer, BEC and targets TMOTOR F7 V2 via Betaflight/INAV.
Upon receiving your FC,please connect to USB and calibrate before continuing to build and solder to it.
Bullet points
- Built-in SpeedyBee Wi-Fi & & Bluetooth
- BetaFlight tuning wirelessly
- Flash firmware wirelessly
- Analyze Black-box data wirelessly
- Set motor directions on BLHeli_32/S wirelessly
- Target : TMOTOR F7 V2
- UART1 : VTX/TX
- UART2 : Receiver (CRSF/SBUS/iBUS/DSMX/R9MM)
- UART3 : GPS
- UART4 : ESC telemetry/RX
- UART5 : Vacancy
- UART6 : Vacancy
Specifications
- MCU : STM32F722 RET6
- IMU : ICM42688
- Barometer : BMP280
- Input voltage : 3-8S
- BEC Output : 10V/2A 5V/3A
- Built-in OSD (AT7456)
- Built-in 16Mb Flash for data logging
- ESc signal : M1 - M8
- Size : 37*37*7.5mm
- Installing hole : 30.5*30.5mm/M3
- USB : Type-C
- Weight : 8.1g
Included
- 1x F7 PRO Flight Controller
Customer reviews
Excellent appareil
Le 8S en o3 ok 👍
FC qui chauffe énormément en beta 4.4 obligé de rester en 4.2.9 donc pas de "rth" des version 4.4 c'est vraiment dommage pour une carte pro.
great FC for x8 cinelifter
Vraiment cool pour les cinélifter
Super qualité. Le bluetooth déconne un peu cela dit..... dommage... Sinon super fc !
